3M VHB Tape Max-160GF Extra Strength Double Sided Acrylic Foam Tape, 62 mil Thickness
Fill out the details below and we'll get pricing right over to you.
3M VHB Tape Max-160GF Extra Strength Double Sided Acrylic Foam Tape, 62 mil Thickness
20 product options available.
3M VHB Max-160GF 62 mil Acrylic Foam Tape for Demanding Applications
3M VHB Max-160GF is a 62 mil (1.6 mm) gray double-sided acrylic foam tape designed for assemblies that demand both thickness and strength. When used with 3M VHB Max Promoter, it achieves at least 2x the strength of standard VHB tapes, with overlap shear values up to 345 psi for reliable structural bonding.
Engineered for high-stress applications, this tape helps manufacturers reduce reliance on rivets, screws, and liquid adhesives while improving efficiency on the production line. Whether bonding exterior panels on vehicles, securing architectural facades, or assembling appliances and industrial equipment, 3M VHB Max-160GF delivers lasting durability with a clean, seamless appearance.
Why 3M VHB Max-160GF Stands Out
- Proven Strength: Delivers overlap shear values up to 345 psi with 3M VHB Max Promoter — providing at least twice the performance of standard VHB tapes.
- Thicker Profile: At 62 mil (1.6 mm), this tape supports larger, heavier components where durability is critical.
- Production Efficiency: Immediate handling strength speeds up assembly and reduces steps compared to liquid adhesives.
- Design Flexibility: Eliminates drilling, welding, and fasteners to create clean, smooth finishes with greater creative freedom.
- Broad Application Range: Bonds effectively to metals, high surface energy plastics, and coated surfaces.
- Optimized System: Designed to be paired with 3M VHB Max Promoter for maximum and consistent bond reliability.
Specifications
- Series: VHB Max
- Model: VHB Max-160GF
- Type: Double-Sided Acrylic Foam Tape
- Total Thickness (w/o liner): 62 mil (0.062 in) (1.6 mm)
- Foam Type: Firm
- Color: Gray
- Liner Material: Polyethylene Film
- Core Size: 3 in (76.2 mm)
- Shelf Life: 24 months from date of manufacture
- 90° Peel Adhesion: 63 lb/in (111 N/cm)
- Normal Tensile Strength: 250 lb/in² (1.7 MPa)
- Overlap Shear Strength: 345 psi (2.4 MPa) with 3M VHB Max Promoter
- Available Sizes: 1/2 in x 36 yd, 3/4 in x 36 yd, 1 in x 36 yd, 22 in x 36 yd, custom widths available
- Substrates: Bonds to a variety of high surface energy (HSE) and medium surface energy (MSE) materials including metals, glass, paints, and plastics
- Promoter Requirement: Use with 3M VHB Max Promoter to achieve maximum bond strength
Common Applications for VHB Max Tape
- Commercial Vehicles: Attach exterior panels, trim, vents, and stiffeners on trucks, trailers, and buses.
- Building & Construction: Bond cladding, wall panels, and decorative metal features for clean architectural finishes.
- Appliances: Secure control panels, decorative trims, and touchscreens with lasting strength.
- Electronics: Mount displays, bezels, and glass panels to create slim, durable assemblies.
- Industrial Manufacturing: Replace rivets, welds, and screws in panel bonding, stiffener attachment, and semi-structural applications.
Submit the form below to get the Technical Data Sheet (TDS) or Safety Data Sheet (SDS) for 3M VHB Max-160GF sent to your email address.
Questions about 3M VHB Max-160GF? Our team of adhesive specialists can help. Submit your questions and we'll get you answers right away.
3M VHB Max Tape
3M VHB Max Series acrylic foam tapes are available in 25, 45, 62, and 90 mil thicknesses. They come in standard rolls or can be custom cut to size.
