3M VHB Tape Max-110GF Extra Strength Double Sided Acrylic Foam Tape, 45 mil Thickness

3M VHB Max-110GF Heavy-Duty 45 mil Double-Sided Tape

3M VHB Max-110GF is a 45 mil (1.1 mm) gray double-sided acrylic foam tape built for high-strength bonding in demanding applications. When combined with 3M VHB Max Promoter, it delivers at least 2x the strength of standard VHB tapes, achieving overlap shear values up to 395 psi.

This heavy-duty tape provides the holding power required for larger or more demanding assemblies while reducing reliance on rivets, welds, or liquid adhesives. From commercial vehicles and rail cars to appliances, architectural panels, and general industrial designs, 3M VHB Max-110GF offers durable bonds, simplified production, and clean, seamless results.

Key Features of 3M VHB Max-110GF Tape

• Exceptional Bond Strength: Achieves overlap shear values up to 395 psi when paired with 3M VHB Max Promoter — at least 2x stronger than standard VHB.
• Heavy-Duty Thickness: At 45 mil (1.1 mm), this tape is engineered for demanding bonding applications that require added holding power.
• Fast and Efficient Assembly: Provides immediate handling strength, helping reduce steps compared to welding or liquid adhesives.
• Cleaner, Seamless Design: Eliminates drilling, rivets, and mechanical fasteners, leaving smooth finishes and enhanced aesthetics.
• Trusted Versatility: Performs across metals, high surface energy plastics, and coated surfaces for broad industrial use.
• Perfect Pairing: Designed to be used with 3M VHB Max Promoter for maximum bond reliability in tough conditions.

VHB Max-110GF Specifications

• Series: VHB Max
• Model: VHB Max-110GF
• Type: Double-Sided Acrylic Foam Tape
• Total Thickness (w/o liner): 45 mil (0.045 in) (1.1 mm)
• Foam Type: Firm
• Color: Gray
• Liner Material: Polyethylene Film
• Core Size: 3 in (76.2 mm)
• Shelf Life: 24 months from date of manufacture
• 90° Peel Adhesion: 53 lb/in (92 N/cm)
• Normal Tensile Strength: 275 lb/in² (1.9 MPa)
• Overlap Shear Strength: 395 psi (2.7 MPa) with 3M VHB Max Promoter
• Available Sizes: 1/2 in x 36 yd, 3/4 in x 36 yd, 1 in x 36 yd, 22 in x 36 yd, custom widths available
• Substrates: Bonds to a variety of high surface energy (HSE) and medium surface energy (MSE) materials including metals, glass, paints, and plastics
• Promoter Requirement: Use with 3M VHB Max Promoter to achieve maximum bond strength

Applications for VHB Max Tape

• Transportation: Secure side panels, roof components, trim, and nameplates on trucks, buses, and rail cars.
• Appliances: Attach decorative trim, control panels, and touchscreens with long-lasting strength.
• Construction: Bond architectural panels, cladding, and interior fixtures for clean, fast installation.
• Electronics: Mount bezels, displays, and lenses to create slim, seamless device assemblies.
• General Industrial: Replace rivets, screws, and welds in stiffener attachment, panel bonding, and other structural assemblies.
