Graco 130402 Dual Orifice Right Angle Hot Melt Nozzle, 0.028 in Orifice, 90°/60° Pattern

SKU: GRACO 130402

Manufacturer Part #: 130402

UPC: 00755652637905

19 product options available.

Type: Hot Melt Nozzle
Brand: Graco
Description: 2 Orifice Right Angle Nozzle, 0.028" Orifice, 90°/60° Pattern
Nozzle Type: 2 Orifice, Right Angle
Nozzle Angle: 90 Degree / 90/60 Degree Spread
Orifice Size: .028"

Graco 130402 Dual Orifice Right Angle Hot Melt Nozzle for InvisiPac™ Applicators

The Graco 130402 is a dual-orifice replacement hot melt nozzle designed to dispense adhesive in a right-angle direction for packaging applications. It features two 0.028 in orifices with 90°/60° dispense angles and is used in case and carton sealing operations on Graco InvisiPac™ applicators.

Graco 130402 Right Angle Hot Melt Nozzle Features and Benefits

Nozzle Body Orientation: Right angle nozzle configured with a combined 90°/60° dispense pattern.
Outlet Configuration: Two adhesive outlets arranged for multi-angle dispensing.
Orifice Dimensions: Includes dual 0.028 in adhesive outlets.
Packaging Use: Used for case sealing, carton closing, and packaging adhesive dispensing.

Technical Specifications

Manufacturer: Graco
Manufacturer Part Number: 130402
Product Type: Hot Melt Nozzle
Nozzle Style: Right Angle
Orifice Count: 2
Orifice Diameter: 0.028 in
Dispense Pattern: 90°/60°
Compatible Equipment: Graco InvisiPac™ Applicators
Application: Case and Carton Sealing, Packaging Adhesive Dispensing

Hotmelt.com is powered by APPLIED Adhesives, your single source for adhesives, dispensing equipment, and expert service. We provide everything you need to keep your operations running smoothly.

Our end-to-end solutions help you save time, reduce costs, and improve efficiency. Whether you need hot melt adhesives, equipment repair, or reliable replacement parts, we have you covered.

Questions about Graco 130402 Nozzle? Our team of adhesive specialists can help. Submit your questions and we'll get you answers right away.

View all Graco 2-Orifice Right-Angle Nozzles

Graco Part #	DESCRIPTION
GRACO 130211	2 Orifice Right Angle Nozzle, 0.012" Orifice, 15° Pattern
GRACO 130212	2 Orifice Right Angle Nozzle, 0.014" Orifice, 15° Pattern
GRACO 130213	2 Orifice Right Angle Nozzle, 0.016" Orifice, 15° Pattern
GRACO 130214	2 Orifice Right Angle Nozzle, 0.018" Orifice, 15° Pattern
GRACO 130215	2 Orifice Right Angle Nozzle, 0.020" Orifice, 15° Pattern
GRACO 130216	2 Orifice Right Angle Nozzle, 0.024" Orifice, 15° Pattern
GRACO 130217	2 Orifice Right Angle Nozzle, 0.028" Orifice, 15° Pattern
GRACO 130218	2 Orifice Right Angle Nozzle, 0.012" Orifice, 30° Pattern
GRACO 130219	2 Orifice Right Angle Nozzle, 0.014" Orifice, 30° Pattern
GRACO 130220	2 Orifice Right Angle Nozzle, 0.016" Orifice, 30° Pattern
GRACO 130221	2 Orifice Right Angle Nozzle, 0.018" Orifice, 30° Pattern
GRACO 130222	2 Orifice Right Angle Nozzle, 0.020" Orifice, 30° Pattern
GRACO 130223	2 Orifice Right Angle Nozzle, 0.024" Orifice, 30° Pattern
GRACO 130224	2 Orifice Right Angle Nozzle, 0.028" Orifice, 30° Pattern
GRACO 130400	2 Orifice Right Angle Nozzle, 0.012" Orifice, 90°/60° Pattern
GRACO 130401	2 Orifice Right Angle Nozzle, 0.020" Orifice, 90°/60° Pattern
GRACO 130402	2 Orifice Right Angle Nozzle, 0.028" Orifice, 90°/60° Pattern
GRACO 130403	2 Orifice Right Angle Nozzle, 0.014" Orifice, 90°/60° Pattern
GRACO 130404	2 Orifice Right Angle Nozzle, 0.016" Orifice, 90°/60° Pattern
